Feature

    ☆ 2 detection zones to carry out double knock release control
    ☆ 1 auxilary zone for usual fire detection
    ☆ All lines monitored for open/short circuit
    ☆ Easy to shift between primary and standby release outputs
    ☆ Individual disable button for zones for easy operation
    ☆ Counting down timer display
    ☆ Adjustable delay timer and release output period
    ☆ Build-in charger and power supply

Technical Specifications

    ☆ Primary Supply: 2201230VAC,50160Hz
    ☆ Standby Power: 7AH124VDC
    ☆ Zone Quantity: 2+1
    ☆ Zone Capacity: 15 detectors
    ☆Output current:
           AUX Power: 100mA
           Souder Output: 500mA
           Release Output: 2.0A
    ☆ Delay time: 0-90s, step @10s
    ☆ Cylinder pulse: 2-45s
    ☆ Protection: IP30
    ☆Operating Environment:
           0°C~+40°C
           ≦95%, non condensing
    ☆ Dimensions: 300mm(w)x350mm(H)x110mm(D)
