Feature

    ☆ Electrically addressed, can be modified by programmer
    ☆ Fault self-diagnostic
    ☆ Rate of rise detection can be switched off
    ☆ Reed switch test
    ☆ Fire LED allows 360° viewing
    ☆ LED indication for both fire and normal status
    ☆ LED indication for normal status can be turned off by handheld
        programmer
    ☆ Output terminal for remote indicator available
    ☆ Comply with UL 521

Technical Specifications

    ☆ Operating Voltage: Loop 24VDC(16VDC~28VDC)
    ☆ Standby Current: ≤0.6mA
    ☆ Alarm Current:
           ≤1.5mA (without remote indicator
           ≤3.5mA (with remote indicator)
    ☆ LED Indicator:
           Red
           Normal: Flash on polling
           Fire: Steadily ONg
    ☆ Remote Indicator Output:
           Polarity-sensitive output, Directly connects to remote indicator
          (built in 10k resistor in series. Maximum outputcurrent is
          2.0mA)
           The remote indicator is quiet in pollingand will flash in
          alarming
           Relative Humidity: 95%, non-condensing
    ☆ Programming Method: Electronically programming
    ☆ Code Range: 1~242
    ☆ Sensitivity:
          Action Temperature 135°F(57.2°C):
          Response rate of rise:15°F/min (8.3℃/min)
    ☆ UL Temperature Range: 32°F(0°C)-100'F(37.8°C)
    ☆ Operating Temperature: 14°F(-10°C)-122°F(+50°C)
    ☆ Relative Humidity: ≤95%, non condensing
    ☆ Material of Enclosure: ABS White (RAL 9016)
    ☆ Ingress Protection Rating: IP2X
    ☆ Dimensions
          Diameter:100mm
          Height: 53.3mm (with base)
    ☆ Mounting Hole Distance: 45mm~75mm
    ☆ Weight: About 110g
