Feature
☆ Sandwich structure
☆ Loop powered
☆ 16 programmable tones
☆ Three working modes
☆ Electronically addressed
☆ Suitable for DI series intelligent detectors
☆ LPCB Approved
Technical Specifications
☆ Operating Voltage: 24VDC
☆ Operating Current:
Standby Current: 1mA
Action Current: 6mA
☆ Alarm tones: 16 tones, Tone 14 and Tone 16 are EN54-3 compliant
☆ Operating Environment:
Temperature -10℃ ~+50℃
Relative Humidity: 95%, non condensing
☆ Dimension: Diameter 152.4mm, Height 43mm
|
