☆Electrically addressed
   ☆Strong environmental adaptability due to drift compensation
   ☆Self-diagnostic
   ☆Reed switch test
   ☆Dirty chamber checking
   ☆LED for 360° vision
   ☆Possible to switch off pulling LED
   ☆Remote indicator output
   ☆2 levels smoke sensitivities, level 1 complies with EN 54-7
   ☆LPCB Approved

Technical Specifications

    ☆Standard: EN54-5, EN54-7
    ☆Operating Voltage: 24VDC
    ☆Operating Current:
           Standby Current: 0.8mA
           Alarm Current: 1.8mA (without remote indicator)
    ☆Operating Environment:
           Temperature: -10℃ ～+50℃
           Relative Humidity: 95%, non condensing
    ☆Programmable Sensitivity:
           Smoke Sensitivity: 2 levels
           Detector Class: A2R
    ☆Dimensions: Diameter 100mm, Height 54.5mm (with base)
