DC-M9504 Base Mount Isolator |
|
Features ☆Polarity-sensitive external connections. Input and outputcan be used inversely without direction. ☆Delayed power-up to output end devices, avoids strongtransient current when the load is heavy Technical Specifications ☆Operating Voltage: 24VDC ☆Standby Current: ≤150uA ☆Capacity: Devices quantity between 2 isolators shouldfollow local codes but cannot exceed 70devices. ☆Indicator: Yellow, flashes when polling, illuminatesin action. ☆Ingress ProtectionRating: IP33 (with cover) IP22 (without cover) ☆Operating Temperature: 0°C~+49°C ☆Relative Humidity: ≤93%, non condensing ☆Material of Enclosure: Flame-retardant ABS (PA-765A), white. ☆Dimension: 100mmx39mm ☆Weight: About 100g |
Download：DC-M9504_DS10105137 Datasheet
