Feature

    ☆Drift compensation enables strong environmental adaptability
    ☆Integrated algorithm for analyzing fire, improving the sensitivity
       highly
    ☆Self-diagnostic
    ☆Reed switch test
    ☆Removable innovative sensing chamber, easy for maintenance
    ☆Reporting dirt fault for contaminated chamber
    ☆Fire LED allows 360°viewing
    ☆3-level sensitivities and fixed temperature or rate of rise
       programmable

Technical Specifications

    ☆ Operating Voltage: 24V(16V~28V)
    ☆ Standby Current: ≤60μA
    ☆ Alarm Current: 10mA≤|≤30mA
    ☆ Indicator: Red. Flashes in polling, and illuminates in alarm
    ☆ Explosion-proof Mark: Ex ibIC T6 Gb
    ☆ Explosion-proofCertificate: CE21.0155
    ☆ Zener Barrier; Uo=28V, lo=93mA, C0=0.083uF, L0=4mH，
        P0=651mW
    ☆ Alarm Clear: Instantaneous Power-of(2s Min.. 1.0VDC MAX.)
    ☆ Smoke Sensitivity Level: 3
    ☆ Heat Sensitivity: Action Temperature:135°F(57.2°C)
        Response Velocity: 15°F /min (8.3°C /min)
    ☆ Environment Temperature: 0'C~37.8°C
    ☆ Relative Humidity: ≤95%, non condensing
    ☆ Material of Enclosure: ABS
    ☆ Dimensions: Diameter:100mm
        Height: 54.5mm (with base)
    ☆ Mounting Hole Distance: 45mm~75mm
    ☆ Weight: About 110g
