Feature

    ☆Large monitoring areas
    ☆ The detector's optical pathway is designed with
        stronganti-interference ability.
    ☆ Attractive and decent appearance.
    ☆ Integration of the emitting and receiving part enableseasy
        installation and accurate optical pathway
    ☆ Built-in microprocessor enables intelligent judgment offire alarm
        and fault
    ☆ Easy alignment ensures a single person installation
    ☆ Self-diagnostic
    ☆ Drift-compensation for factors weakness, such as
        dustcontamination, positional excursion and componentageing
    ☆ 2 Integrated functions for both addressable andconventional
        use

Technical Specifications

    ☆Operating Voltage: 24VDC(15VDC-28VDC)
    ☆ Operation Current:
             Loop:≤ 2mA
             24VDC:Standby current s≤ 12mA
                          Alarm current ≤ 22mA
    ☆ Indicator:
             Commission: Green LED and yellow LED illuminates
             or flashes
             Monitoring state: Red LED flashes
                                         Fire: Red LED illuminates
                                         Fault: Yellow LED illuminates
    ☆  Programming Mode: Electronically programming,1~242
    ☆ Beam width: 14 meters
    ☆ Beam Length: 8-100 meters
    ☆ Protection area: Maximum 1400m2
    ☆ Sensitivity Levels: 2
    ☆ Output relay: 2AV28VDC
    ☆ Ingress Protection: IP66
    ☆ Material and Color: Stainless steel, metallic gray
    ☆ Ambient Temperature: -20°C~+55°C
    ☆ Relative Humidity: ≤95%RH,non-condensing
    ☆ Dimensions: 344mm(L)x240mm(W)x212mm(D)
    ☆ Weight: Detector: 6kg Adjustment frame: 3.8kg
