Feature

    ☆ Drift compensation, to suit environment changing extensively
    ☆ Local buzzer alarm
    ☆ Self-diagnostic
    ☆ Relay output for fan control and Valve shut off

Technical Specifications

    ☆ Working Voltage: 187VAC– 253VAC
    ☆ Power Consumption:
             Standby State≤3.0W
             Alarm States≤5.0W
    ☆ Indicator:
             Power LED: Green
             Alarm/Fault LED: Dual color , red when alarming, and yellow
             in fault.
    ☆ Buzzer:
             Sounds twice per second when alarming,and once every
             three seconds in fault.
    ☆ Self-test:Pressing Self-Test, the LEDs will flash inturn and the
        buzzer will sound three times.
    ☆ Type of Gas: Liquefied Petroleum Gas
    ☆ Alarm Threshold: 2200×10-6(10%LEL)
    ☆ Life of Sensor: 5 years
    ☆ Ingress Protection: IP30
    ☆ Temperature: -10°C ~ +50°C
    ☆ Relative Humidity: ≤95%,non-condensing
    ☆ Material: ABS
    ☆ Weight: 320g
    ☆ Mounting Hole Distance: 23mm
    ☆ Dimension: 121mm×87mm×47mm
